12 LED Side Pin T10 Wedge Base

  • Code: 12LEDT10SP
  • |
  • Stock: In Stock

The 12 LED T10 is ideal for ceiling lights. Designed to sit sideways into the light fitting.

Regulated from 10-30V
Diameter – 30mm
Approximate light output 220lm
2.0W power consumption
Not polarity sensitive
3 year guarantee

The T10 fitting is most commonly found in American RVs and fifth wheelers and is commonly used in ceiling lights, downlights and marker lights. The tungsten T10 is easily replaced with an LED alternative. The tungsten T10 is easily identified as a small glass lamp with two short pins folded back over the wedge based glass. Our LED replacements have a plastic collar which is the same size as the wedge base. In order to identify the most suitable replacement for the T10 lamp it is necessary to find whether the lamp fits sideways or straight back into the fitting as well as what space is available in the fitting to help identify which type to select. There are two styles of LED T10 replacements, discs or towers. The disc types are used to provide light in one direction and are best used where light is required in a single direction, e.g. in ceiling lights and downlights. The tower types provide light in all directions and are suitable to light up wall lights, marker lights and large fittings found in American RVs. All of our T10 LED lamps are voltage regulated and are not polarity sensitive – i.e. the LED will light up whichever way the positive and negative power is applied so no rewiring is required.

£5.29
